200gsm Polypropylene Nonwoven Geotextile For Road Construction Slope Protection And Water And Soil Loss
Product advantages
Good permeability, under the pressure of earthwork, can still maintain good permeability; With polyester, polypropylene and other chemical fibers as raw materials, acid and alkali resistance, no corrosion, no insects, anti-oxidation; Light weight, low cost, simple construction; With excellent filtration, drainage, isolation, reinforcement, protection performance.
| Name | Geotextile |
| Color | Customized |
| Weight (gsm) | 100-800 gsm, customized |
| Size (m/roll) | Customized |
| Material | PET, PP, customized |
| Type | Nonwoven, woven |
| Usage | Civil construction projects |
| Item from | Nominal breaking strength/(KN/m) | | | | | | | | |
| | 3 | 5 | 8 | 10 | 15 | 20 | 25 | 30 | 40 |
| Longitudinal and transverse rupture strength/(kN/m) | 3.0 | 5.0 | 8.0 | 10.0 | 15.0 | 20.0 | 25.0 | 30.0 | 40.0 |
| Elongation% corresponding to nominal breaking strength | 20-100 | 20-100 | 20-100 | 20-100 | 20-100 | 20-100 | 20-100 | 20-100 | 20-100 |
| Breaking strength/kn | 0.6 | 1.0 | 1.4 | 1.8 | 2.5 | 3.2 | 4.0 | 5.5 | 7.0 |
| Mass deviation rate per unit area/% | ±5 | ±5 | ±5 | ±5 | ±5 | ±5 | ±5 | ±5 | ±5 |
| Width deviation rate/% | -0.5 | -0.5 | -0.5 | -0.5 | -0.5 | -0.5 | -0.5 | -0.5 | -0.5 |
| Thickness deviation rate/% | ±10 | ±10 | ±10 | ±10 | ±10 | ±10 | ±10 | ±10 | ±10 |
| Equivalent aperture O90(O95)/mm | 0.07-0.20 | 0.07-0.20 | 0.07-0.20 | 0.07-0.20 | 0.07-0.20 | 0.07-0.20 | 0.07-0.20 | 0.07-0.20 | 0.07-0.20 |
| Vertical permeability coefficient/(cm/s) | kx(10-1--10-3) Among them: k=1.0-9.9 | | | | | | | | |
| Vertical and horizontal tear strength/kN | 0.10 | 0.15 | 0.20 | 0.25 | 0.40 | 0.50 | 0.65 | 0.80 | 1.00 |
| Acid and alkali resistance (strength retention rate)/% | 80 | 80 | 80 | 80 | 80 | 80 | 80 | 80 | 80 |
| Oxidation resistance {strength retention rate}/% | 80 | 80 | 80 | 80 | 80 | 80 | 80 | 80 | 80 |
| UV resistance (strength retention)/% | 80 | 80 | 80 | 80 | 80 | 80 | 80 | 80 | 80 |
Main use of YIXING SHENZHOU GEOTEXTILE
1 Highway and railway tunnel buffer layer. 2 soft foundation reinforcement treatment, slope protection; pavement anti-reflection crack structure layer; drainage system; green isolation belt. 3 Haiti, river embankment, lake lifting project; Reservoir reinforcement project; Reclamation project; Hydropower station project; Flood prevention and emergency rescue. 4 highway pavement maintenance. 5 Cooperate with other materials (mainly asphalt or plastic film) to form an impermeable barrier in the soil layer (mainly use dry road resurfacing, repair, etc.)
More information about our services:
Whatsapp:+86 139 0153 8890
Shenzhou Earth Working Material Co. Ltd
Yixing Shenzhou Geosynthetics was established in 2004, Designed and
manufactured in-house at ISO 9001 certified manufacturing
facilities our line to meets demanding
QA/QC requirements and are continuously tested to rigorous ASTM
standards both in-house and by leading independent geosynthetics.
Product availability:
Plastic Geogrid ( Biaxial / Uniaxial / Triax / Hexagon )
Warp knitted Fiberglass geogrid coated with bitumen
Warp knitted woven coated polyester geogrid
Non Woven Geotextile with PET and PP material. With staple fibre
and filament process
HDPE / LDPE / LLDPE Geomembrane
Geocomposited Geogrid / Geocomposited membrane
GCL
Custimized product
We warmly welcome all friends and customers from home and abroad to
visit our company,give us advice & suggestion,and get win-win
cooperation.
